| Fuse Part Number / Ratings | Cold Resistance (Ohms) | Overload Interrupt Time (Seconds) 1/2/4/ | Maximum I2T (A2 Sec) | |||||
|---|---|---|---|---|---|---|---|---|
| Part Number | Maximum Voltage (VDC) | Current Rating (Amps) | Minimum | Maximum | 250% Nominal Rating | 400% Nominal Rating | 600% Nominal Rating | |
| SM1206-32-1/4 | 32 | 0.250 | 1.500 | 2.500 | .005-60.0 | .0005-.015 | .00005-.003 | NOTE 3 |
| SM1206-32-3/8 | 32 | 0.375 | 1.125 | 1.875 | .005-60.0 | .0005-.015 | .00005-.003 | NOTE 3 |
| SM1206-32-1/2 | 32 | 0.500 | 0.450 | 0.750 | .005-10.0 | .0005-.015 | .00005-.003 | NOTE 3 |
| SM1206-32-3/4 | 32 | 0.750 | 0.198 | 0.331 | .005-10.0 | .0005-.015 | .00005-.003 | NOTE 3 |
| SM1206-32-1.0 | 32 | 1.000 | 0.120 | 0.190 | .005-5.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-32-1.5 | 32 | 1.500 | 0.0825 | 0.1375 | .005-3.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-32-2.0 | 32 | 2.000 | 0.0410 | 0.0680 | .005-3.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-32-3.0 | 32 | 3.000 | 0.0240 | 0.0400 | .005-1.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-24-4.0 | 24 | 4.000 | 0.0184 | 0.0276 | .005-1.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-24-5.0 | 24 | 5.000 | 0.0120 | 0.0200 | .005-1.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-24-6.0 | 24 | 6.000 | 0.0105 | 0.0175 | .005-1.0 | .0005-.010 | .00001-.003 | NOTE 3 |
| SM1206-24-7.0 | 24 | 7.000 | 0.0096 | 0.0144 | .005-1.0 | .0005-.010 | .00001-.003 | NOTE 3 |
